MLN23B39-370500P16000N-C4A0-XXX
Can't find what you're looking for? Go to the Product Selector
Motorized, NEMA 23, 0.0025 英寸 Travel/Step, Double Stack, 3.9 A, Rotating Nut, Nut integral to motor, 0.37 X 0.5 英寸 梯形絲杠
- 混合式步進電機和精密梯形絲杠共同集成在緊湊封裝中。
- 比競爭對手更高的力矩密度
- 更高的效率。
- 噪音更低。
- 絲杠螺母與電機轉子的集成正在專利申請中。
| 尺寸 | 價值 |
|---|---|
| [L1] Screw Length | 16 英寸 |
| [M] | 2.59 英寸 |
| End Machining, Front, [T] | 1/4-20 Thread X 0.500 in |
| End Machining, Rear | No-Machining |
| Screw, Lead | 0.5 英寸 |
| Screw, Nomial Diameter | 0.37 英寸 |
| Travel/Step | 0.0025 英寸 |
| 絲杠跳動 | 0.007 in/ft |
| 絲杠直線度 | 0.005 in/ft |
| Performance | 價值 |
|---|---|
| Load, Max @ Max Speed | 4.16 磅力 |
| Load, Max @ Min Speed | 64.8 磅力 |
| Max Speed (Recommended) | 41.8 英寸每秒 |
| Motor, Step Angle | 1.8 ° |
| Screw, Lead Accuracy | 0.003 in/ft |
| Travel/Step | 0.0025 英寸 |
